Springs Cage Connection Terminal Block

Product Details:
Place of Origin: China
Brand Name: WONKEDQ
Certification: CE/RoHS/CQC/ISO 9001
Model Number: JST 2.5-QUATTRO-PE Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Model:JST 2.5-QUATTRO-PE

Send Inquiry

Product Description

Spring Clamp Terminal Blocks combine flame-resistant PA66 and tin-plated brass for vibration-proof, corrosion-resistant grounding with low resistance. Their 35mm DIN rail snap-on design saves space, while spring-loaded terminals prevent loosening in harsh, high-vibration environments. Easy to install with plug-in bridges and labeling, they ensure reliable PE connections for energy systems.

Part No.	JST 2.5-QUATTRO-PE
Color	Yellow/Green, other color can be customized
Length/Height/Wide (mm)	72.5/35.5/5.2
Connection method	Spring-cage connection
Material	Nylon PA66
Rated Voltage/Current	800V/30A
Cross section, solid/soft Cable	0.2-4mm² / 0.2-2.5 mm²
Conductor Size	24-12 AWG
Mounting Type	NS 35/7.5
Standard	IEC 60947-7-1
LOGO	Customized logo are supported
Packing Detail	12.51g/pc, 65PCS/BOX, 2500PCS/CTN
Certification	CE/RoHS/CQC/ISO 9001
