JST 2.5 TW PE Spring Clamp Terminal Block

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE/RoHS/CQC/ISO 9001
Model Number: JST 2.5-TW-PE
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Model:JST 2.5-TW-PE

Send Inquiry

Product Description

The WonkeDQ spring cage terminal adopts flame-retardant PA66+tin plated copper parts, suitable for wire diameters of 0.5-4mm ², and the yellow green shell complies with IEC grounding. DIN rail quick installation+bridge expansion, spring self-locking and anti loosening design, saving 30% space and labor time. Standard modular accessories, supporting OEM customization, providing corrosion-resistant and airtight connection solutions specifically for high vibration scenarios such as rail transit and energy.

Model No.	JST 2.5-TW-PE
Color	Yellow/Green, other color can be customized
Length/Wide/Height (mm)	61/36/5.2
Connection method	Spring clamp
Material	Flame retardant Nylon PA66
Rated Voltage/Current	800V/65A
Cross section, solid/soft Cable	0.2-4mm² / 0.2-2.5 mm²
Conductor Size	24-12 AWG
Mounting Type	NS 35/7.5
Standard	IEC 60947-7-1
LOGO	Customized logo are supported
Packing Detail	10.69g/pc, 50PCS/BOX, 1500PCS/CTN
Certification	CE/RoHS/CQC/ISO 9001
