Twin Push In Terminal Block

Place of Origin: China
Brand Name: WKDQ
Certification: CE/RoHS/CQC/ISO 9001
Model Number: JPT 2.5 TWIN
Delivery Time: 2-7days

Send Inquiry

Product Description


The Push-In Technology DIN Rail Terminal Blocks utilize a convenient Push-In technology that allows for easy and fast wire connections without the need for tools. Users can simply push ferruled wires directly into the terminal block for quick and secure connections.

These terminal blocks are made from Anti Inflaming Nylon PA 66 material, ensuring high-quality and safety, with a nickel-plated brass bar for reliable conductivity.

The Push-In connection feature enables tool-free wiring of conductors with ferrules or solid conductors, simplifying the installation process.

The compact design and front connection of these terminal blocks make them suitable for wiring in confined spaces, saving valuable space in applications.

In addition to ferruled wires, these terminal blocks also support the connection of stranded wires. By depressing the orange actuator, users can insert the conductor into the terminal block.

The wires are securely retained with a stainless steel leg spring that tightens under tension, ensuring reliable and stable connections.

Equipped with a universal foot, these terminal blocks can be easily installed on Din Rail NS 35, providing flexibility in mounting options.

Furthermore, the Push-In Technology DIN Rail Terminal Blocks are available in a twin configuration, offering a convenient solution for connecting multiple wires side by side, further enhancing their versatility and functionality.

Overall, the Push-In Technology DIN Rail Terminal Blocks, including the twin configuration, offer a user-friendly and efficient solution for wire connections, allowing for quick and reliable installations in various applications.




Model No. JPT 2.5-TWIN
Color Grey, Blue, other color can be customized
Length/Height/Wide (mm) 60.5/36.5/5.2
Connection method Push in connection
Material Nylon PA66
Rated Voltage/Current 800V/31A
Cross section, solid/soft Cable 0.2-4mm² / 0.2-2.5mm²
Conductor Size 24-12 AWG
Mounting Type NS 35 mm
Standard IEC 60947-7-1
LOGO Customized logo are accept
Packing Detail 7.19g/pc, 50PCS/BOX
Certification CE/RoHS/CQC/ISO 9001
