USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²
  • USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²
  • USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²
  • USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²
  • USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²

USLKG 95 Ground Terminal Block Din Rail Installation 95 Mm²

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE, RoHs, CQC,etc
Model Number: JUSLKG 95
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description

The JUSLKG 95 screw type Ground Terminal Block is an industry-standard terminal block designed to securely clamp onto the NS 35 Din Rail by tightening the middle screw. The Din Rail serves as a grounding busbar, distributing ground potential to all other grounding terminals.

Key features of the JUSLKG 95 screw type Ground Terminal Block include:

Made from V0 flame retardant Nylon66/PA66 material, ensuring high safety and protection.

Enclosed insulating case for added insulation and safety.

Long durable lifespan, providing reliable performance over an extended period.

Perfectly suitable for electrical machine control systems, meeting the requirements of such applications.

Comprehensive range of accessories available, including plug-in bridges, marking strips, and marking holders, for convenient and organized wiring connections.

Economical terminal blocks that offer cost-effective wiring solutions and termination locales.

The JUSLKG 95 screw type Ground Terminal Block exhibits typical features that are essential for practical applications.

The terminal blocks feature an enclosed housing made from flame-resistant Nylon, providing additional protection.

Brass conductive elements ensure reliable electrical conductivity.

Green-yellow ground terminal blocks are also available to meet specific safety standards.

Equipped with a universal foot, allowing easy installation on Din Mounting 35mm.

Capable of connecting two conductors easily, including larger conductor cross sections.

The JUSLKG 95 screw type Ground Terminal Block offers a reliable and efficient solution for grounding connections in electrical systems. With its durable construction, flame retardant material, and compatibility with accessories, it ensures safe and secure grounding connections for various applications.


TECHNICAL PARAMETERS

Model Number JUSLKG95
Color Yellow-Green
Length/Height/Wide (mm) 83./82.1/25.2
Connection method Screw connection
Material Nylon PA66
Rated Voltage/Current 1000V/232A
Cross section, solid/soft Cable 25-95 mm² / 35-95 mm²
Conductor Size 4-000 AWG
Mounting Type NS 35 DIN rail
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 194.23g/pc, 120PCS/BOX
Certification CE/RoHS/CQC/ISO 9001
