3326-300 Electrical Cabinet Air Filter , Air Clean Control Panel Ventilation Fan 290mm Surface Waterproof ABS Material
  • 3326-300 Electrical Cabinet Air Filter , Air Clean Control Panel Ventilation Fan 290mm Surface Waterproof ABS Material3326-300 Electrical Cabinet Air Filter , Air Clean Control Panel Ventilation Fan 290mm Surface Waterproof ABS Material
  • 3326-300 Electrical Cabinet Air Filter , Air Clean Control Panel Ventilation Fan 290mm Surface Waterproof ABS Material3326-300 Electrical Cabinet Air Filter , Air Clean Control Panel Ventilation Fan 290mm Surface Waterproof ABS Material

3326-300 Electrical Cabinet Air Filter , Air Clean Control Panel Ventilation Fan 290mm Surface Waterproof ABS Material

Place of Origin: China
Brand Name: WONKEDQ,WKDQ
Certification: CE, RoHs, CQC,etc
Model Number: 3326-300
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description

Model No.: 3326-300 Voltage: 230V
Current: 280mA Rated Air Flow: 230m³/h
Installation Hole Size (mm): 290x290 Input Power Rating: 64W
High Light: electrical cabinet cooling fans , electrical cabinet ventilation fans


WonkeDQ CONTACT has air filters for industrial and consumer applications to clear the air. Install a durable air filter making the unit wokring.We has air filters that help you keep the enclosure air clean, improving the mechanical life.

Frame material is made from heat resistance and anti-flame ABS.

Reliable and safe function.

Other dimension can be customized.

The protection level of sealed box can reach IP54.

The waterproof hood can make the protection level up to IP55.

It can prevent dust particles more than 10 microns.

The rainproof function of ventilation cascade can prevent mechanical damage and damp entering.

It is easy to change the filter pad by using the groove handle on shutter.

The design adapt to current market requirement:Super flat,Fast installation,High power.

Filter pad is made from non-woven fiber, replacing the filters can be made during operation without any risk of touching the rotating parts.

Filter fans and grilles work together to displace hot air inside the enclosure with cooler air from the outside.

The incoming air is filtered to protect components inside the enclosure.

Can clip into the cabinet easily into enclosure wall

OEM is supporting.


TECHNICAL PARAMETERS

Filter unit Part No. 3326-300
Fan with filter unit Part No. 3326-230
Unimpeded air flow 230m³/h
Noise level 59dB
Surface dimension (mm) 320x320
Installation hole size (mm) 290x290
Voltage/Current 230V/280mA
Input Power Rating 64W
Temperature range -10℃~+55℃
Packing detail: 3326-300 (Filter unit) 0.589kgs/pc
Packing detail: 3326-230 (Fitler with Fan) 2.760kgs/pc
Certificate CE, RoHS, CQC
