DIN Rail Terminal Block
  • DIN Rail Terminal BlockDIN Rail Terminal Block
  • DIN Rail Terminal BlockDIN Rail Terminal Block
  • DIN Rail Terminal BlockDIN Rail Terminal Block
  • DIN Rail Terminal BlockDIN Rail Terminal Block

DIN Rail Terminal Block

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE, RoHs, CQC,etc
Model Number: JUSLKG 95
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description


The DIN Rail Terminal Block has become an industry-standard terminal block, and the JUSLKG 95 screw type Ground Terminal Block is no exception. Specifically designed to securely clasp onto the NS 35 Din Rail, these terminal blocks utilize a middle screw to establish a reliable and secure connection. The Din Rail serves as a grounding busbar, distributing ground potential to all other grounding terminals in the system.

Key features of the JUSLKG 95 screw type Ground Terminal Block, including the DIN Rail Terminal Block, include:

High Safety and Protection: Constructed from V0 flame retardant Nylon66/PA66 material, the terminal block ensures a high level of safety and protection in electrical applications.

Enclosed Insulating Case: The terminal block, including the DIN Rail Terminal Block, is equipped with an enclosed insulating case, providing additional insulation and safety measures.

Long Lifespan: Designed for durability, the terminal block, including the DIN Rail Terminal Block, offers a long lifespan, ensuring reliable performance over an extended period.

Suitable for Machine Control Systems: The JUSLKG 95 Ground Terminal Block, including the DIN Rail Terminal Block, is perfectly suited for electrical machine control systems, meeting the specific requirements of such applications.

Comprehensive Range of Accessories: A variety of accessories, including plug-in bridges, marking strips, and marking holders, are available for both the JUSLKG 95 Ground Terminal Block and the DIN Rail Terminal Block, facilitating convenient and organized wiring connections.

Cost-Effective Solution: These terminal blocks, including the DIN Rail Terminal Block, provide economical wiring solutions and termination locales, offering cost-effectiveness without compromising performance.

The JUSLKG 95 screw type Ground Terminal Block, including the DIN Rail Terminal Block, exhibits typical features essential for practical applications. Its enclosed housing is made from flame-resistant Nylon material, ensuring added protection. The conductive elements, including those in the DIN Rail Terminal Block, are constructed from brass, guaranteeing reliable electrical conductivity. Additionally, green-yellow ground terminal blocks are available to meet specific safety standards.

Both the JUSLKG 95 screw type Ground Terminal Block and the DIN Rail Terminal Block are designed with a universal foot, allowing for easy installation on Din Mounting 35mm. They offer the capability to connect two conductors, including larger conductor cross sections, with ease.

The JUSLKG 95 screw type Ground Terminal Block and the DIN Rail Terminal Block provide reliable and efficient solutions for grounding connections in electrical systems. With their durable construction, flame retardant material, and compatibility with accessories, they ensure safe and secure grounding connections for various applications.



Model Number JUSLKG95
Color Yellow-Green
Length/Height/Wide (mm) 83./82.1/25.2
Connection method Screw connection
Material Nylon PA66
Rated Voltage/Current 1000V/232A
Cross section, solid/soft Cable 25-95 mm² / 35-95 mm²
Conductor Size 4-000 AWG
Mounting Type NS 35 DIN rail
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 194.23g/pc, 120PCS/BOX
Certification CE/RoHS/CQC/ISO 9001
