JUKH 240 Din Rail Terminal Blocks High Current 240mm² For Potential Distribution NS 35mm

Place of Origin: China
Brand Name: WKDQ
Certification: CE, RoHs, CQC,etc
Model Number: JUKH 240
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description

The Screw Clamp DIN Rail Terminal Block is designed for a single terminal connection and is compatible with 2-pole feed through applications. Here are the key features and benefits:

Easy to Operate: The terminal block is designed for ease of use, simplifying the installation and wiring process.

Safe and Reliable Connection: It ensures a secure and dependable electrical connection, minimizing the risk of loose connections or disruptions.

Screw Self-Locking: The terminal block utilizes an elastic structure to achieve screw self-locking, providing added stability and security.

Enclosed Insulating Case: The terminal block is enclosed in an insulating case, enhancing safety and preventing accidental contact with live components.

High Current Grounding Terminals: It offers high-current grounding terminals, enabling efficient grounding connections.

Flame-Retardant Construction: The terminal block is made from industrial flame-retardant nylon PA66, providing resistance to flames and ensuring a safer operation.

Guaranteed Quality: All materials used in the terminal block are guaranteed to be of high quality, ensuring long-lasting performance and durability.

Strong Contact Force and Low Contact Resistance: The terminal block features a strong contact force and low contact resistance, ensuring efficient power transmission and minimizing energy loss.

Corrosion-Proof Contact Points: The contact points of the terminal block are designed to be corrosion-proof, enhancing longevity and maintaining a reliable connection over time.

Electrical Distribution Capability: The terminal block can utilize bridges in the terminal center to build electrical distribution systems, allowing for easy expansion and customization.

Comprehensive Range of Accessories: A variety of accessories are available for the terminal block, including end covers, end stoppers, partition plates, marker trips, fixed bridges, insertion bridges, and more, providing flexibility and customization options.

In summary, the Screw Clamp DIN Rail Terminal Block offers an easy-to-operate, safe, and reliable solution for electrical connections. With its high-quality construction, flame-retardant materials, and corrosion-proof contact points, it provides a strong and durable connection. The option to use bridges for electrical distribution and the availability of various accessories further enhance its versatility and adaptability to different applications.


TECHNICAL PARAMETERS

Model No. JUKHN 240
Color Grey, Blue, other color can be customized
Length/Height/Wide (mm) 101/126/37
Connection method Screw connection
Material Nylon PA66
Voltage/Current 1000V/415A
Cross section 70-240 mm² / 70-240 mm²
Conductor Size 00-500 AWG
Mounting Type NS 35/7.5
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 468.11g/pc, 5PCS/BOX, 40PCS/CTN
Certification CE/RoHS/CQC/ISO 9001
