Screw Din Rail Terminal Block
  • Screw Din Rail Terminal BlockScrew Din Rail Terminal Block
  • Screw Din Rail Terminal BlockScrew Din Rail Terminal Block
  • Screw Din Rail Terminal BlockScrew Din Rail Terminal Block
  • Screw Din Rail Terminal BlockScrew Din Rail Terminal Block
  • Screw Din Rail Terminal BlockScrew Din Rail Terminal Block

Screw Din Rail Terminal Block

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE, RoHs, CQC,etc
Model Number: JUKK 5
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description

The WonkeDQ Terminal blocks are constructed using engineering flame retardant nylon PA66 with brass screw metal, ensuring high durability and safety. These terminal blocks are designed with a universal foot, allowing for easy installation on Din Rail NS 35.

One of the key advantages of these terminal blocks is their ability to effortlessly connect two conductors, including those with large cross sections. They provide a secure and reliable connection for various electrical applications.

To facilitate electric potential distribution, the terminal blocks offer options for fixed bridges in the terminal center or insertion bridges in the clamping space. This flexibility allows for efficient and customizable wiring configurations.

To complement the terminal blocks, WonkeDQ provides a wide range of accessories including end covers, end stoppers, partition plates, marker trips, fixed bridges, insertion bridges, and more. These accessories enhance the functionality and versatility of the terminal blocks, ensuring a comprehensive solution for your electrical needs.

Part No. JUKK 5, Multi Levels Terminal Blocks
Color Grey, Blue, other color can be customized
Length/Height/Wide (mm) 57/62/6.2
Connection method Screw connection
Material Nylon PA66
Rated Voltage/Current 500V/32A
Cross section, solid/soft Cable 0.2-4 mm² / 0.2-4 mm²
Conductor Size 24-12 AWG
Mounting Type NS 35/7.5
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 13.66g/pc, 50PCS/BOX, 2000PCS/CTN
Certification CE/RoHS/CQC/ISO 9001
