Screw Terminal Block High Voltage
  • Screw Terminal Block High VoltageScrew Terminal Block High Voltage
  • Screw Terminal Block High VoltageScrew Terminal Block High Voltage
  • Screw Terminal Block High VoltageScrew Terminal Block High Voltage
  • Screw Terminal Block High VoltageScrew Terminal Block High Voltage
  • Screw Terminal Block High VoltageScrew Terminal Block High Voltage

Screw Terminal Block High Voltage

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE, RoHs, CQC,etc
Model Number: JUKH 95
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description

The JUKH High current terminal blocks are designed to provide a secure and dependable connection with exceptional construction features. These terminal blocks offer several advantages that ensure a safe and reliable electrical connection. Here are the key details about these terminal blocks:

  1. Three-Point Centering and Fluted Contact Surface: The terminal blocks feature a prism-shaped sleeve base that centers the wire at three points, ensuring a secure and stable connection. Additionally, the fluted contact surface reduces contact resistance, enabling efficient electrical conductivity.

  2. Self-Locking Screws with Elastic Structure: The terminal blocks utilize an elastic structure that enables self-locking of the screws. This feature ensures that the screws remain securely fastened, enhancing the stability of the connection.

  3. Industrial Flame Retardant Nylon PA66 Construction: The terminal blocks are constructed from high-quality industrial flame retardant nylon PA66 material. This robust material provides excellent durability and safety, making the terminal blocks suitable for demanding applications.

  4. Enclosed Insulating Case: Each terminal block is equipped with an enclosed insulating case, which offers insulation and protection for the electrical connections. This feature enhances safety and prevents accidental contact with live components.

  5. Long Lifespan: The terminal blocks are designed to have a prolonged lifespan, ensuring reliable performance over an extended period. This durability reduces the need for frequent replacements, saving time and maintenance costs.

  6. Ideal for Electrical Machine Control Systems: These terminal blocks are specifically well-suited for various electrical machine control systems. They meet the requirements of different applications, providing a versatile solution for connecting and controlling electrical components.

  7. Comprehensive Range of Accessories: The terminal blocks come with a wide range of accessories to enhance convenience and organization in wiring installations. These accessories include plug-in bridges, marking strips, and marking holders, allowing for efficient and organized wiring setups.

  8. DIN Mounting Compatibility: The terminal blocks feature a universal foot design, allowing them to be easily installed on DIN mounting rails with a width of 35mm. This compatibility simplifies installation and ensures a secure mounting of the terminal blocks.

  9. Easy Accommodation of Two Conductors: The terminal blocks are designed to accommodate two conductors effortlessly, even larger cross-sections. This feature eliminates any difficulties in connecting multiple wires, enhancing the flexibility and versatility of the terminal blocks.

In conclusion, the JUKH High current terminal blocks offer a secure and reliable electrical connection. With their superior construction, industrial flame retardant nylon PA66 material, enclosed insulating case, and self-locking screws, these terminal blocks provide durability, safety, and ease of use. They are suitable for various electrical machine control systems and come with a comprehensive range of accessories. The compatibility with DIN mounting rails and the ability to accommodate two conductors make these terminal blocks versatile and practical for a wide range of applications.

Model Number JUKH 95
Color Grey, Blue, other color can be customized
Length/Height/Wide (mm) 83/90.5/25
Connection method Screw connection
Material Nylon PA66
Rated Voltage/Current 1000V/232A
Cross section, solid/soft Cable 25-95 mm² / 35-95 mm²
Conductor Size 4-000 AWG
Mounting Type NS 35 DIN rail
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 194.23g/pc, 120PCS/BOX
Certification CE/RoHS/CQC/ISO 9001
