Screw type terminal block
  • Screw type terminal blockScrew type terminal block

Screw type terminal block

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE, RoHs, CQC,etc
Model Number: JUSLKG 95
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description

The JUSLKG 95 screw type Ground Terminal Block is a widely used solution for grounding applications in various industries. It offers secure clamping onto the NS 35 Din Rail by tightening the middle screw, allowing the rail to serve as a grounding busbar and distribute ground potential to all other grounding terminals.

Key features of the JUSLKG 95 screw type Ground Terminal Block include:

Enhanced safety: The terminal block is made from V0 flame retardant Nylon66/PA66, ensuring a high level of safety in grounding applications.

Insulating case: The terminal block is enclosed in an insulating case to prevent accidental contact and ensure electrical safety.

Durable lifespan: The terminal block is designed for long-lasting performance, providing reliable grounding connections over an extended period.

Suitable for electrical machine control systems: The JUSLKG 95 terminal block is perfectly suitable for use in electrical machine control systems, offering efficient grounding solutions.

Comprehensive range of accessories: A variety of accessories such as plug-in bridges, marking strips, and marking holders are available for the terminal block, allowing for customization and enhanced functionality.

Economical solution: The terminal block offers an economical solution for convenient wiring connections and termination locales, providing cost-effective grounding options.

Housing materials: The terminal block features a housing made from flame-resistant Nylon and brass conductive elements, ensuring durability and reliable performance.

Green-yellow ground terminal blocks: Green-yellow ground terminal blocks are also available, offering easy identification and compliance with grounding standards.

Universal foot: The terminal block is designed with a universal foot, allowing for easy installation on Din Mounting 35mm, providing versatility and compatibility.

Accommodates large conductor cross sections: The terminal block is capable of easily connecting two conductors, accommodating even large conductor cross sections, ensuring flexibility in grounding applications.

In summary, the JUSLKG 95 screw type Ground Terminal Block combines practical features such as enhanced safety, durability, a comprehensive range of accessories, and economical wiring solutions. Its compatibility with Din Mounting 35mm and ability to accommodate large conductor cross sections make it a reliable and efficient choice for various grounding applications in different industries.

Model Number JUSLKG95
Color Yellow-Green
Length/Height/Wide (mm) 83./82.1/25.2
Connection method Screw connection
Material Nylon PA66
Rated Voltage/Current 1000V/232A
Cross section, solid/soft Cable 25-95 mm² / 35-95 mm²
Conductor Size 4-000 AWG
Mounting Type NS 35 DIN rail
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 194.23g/pc, 120PCS/BOX
Certification CE/RoHS/CQC/ISO 9001
