Place of Origin: China
Brand Name: WKDQ
Certification: CE/RoHS/CQC/ISO 9001
Model Number:UT10-PE
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc
The UT10-PE high-performance screw grounding terminal block is specially designed for industrial/commercial high-current grounding. With a 10mm² capacity, it is suitable for control cabinets, power distribution networks and heavy machinery. The DIN rail is easy to install. The screw connection is anti-vibration and airtight, and it is compatible with fixed/twisted copper wires. The high-quality flame-retardant material is heat-resistant and impact-resistant, meeting industry standards and being reliable and durable.
TECHNICAL PARAMETERS
Model Number | UT10-PE |
Color | Grey, Blue, other color can be customized |
Length/Height/Wide (mm) | L47/H46.9/W10.2 mm |
Connection method | Screw connection |
Material | Flame resistant Nylon PA66,Tin plated copper conductor |
Rated Voltage/Current | 1000V/76A |
Cross section, solid/soft Cable | 0.5-16mm²/0.5-10mm² |
Conductor Size | 20-8 AWG |
Mounting Type | DIN Rail NS 35 |
Standard | IEC 60947-7-1 |
LOGO | WKDQ, OEM serivce is supporting |
Packing Detail | 9.3g/PC, 100PCS/BOX, 3000PCS/CTN |
Certification | CE/RoHS/CQC/ISO 9001 |
