9805-300 Electrical Filter Fans For Enclosures IP55 Safe Grade Non Woven Fiber Pad Waterproof Fit For Current Market
  • 9805-300 Electrical Filter Fans For Enclosures IP55 Safe Grade Non Woven Fiber Pad Waterproof Fit For Current Market9805-300 Electrical Filter Fans For Enclosures IP55 Safe Grade Non Woven Fiber Pad Waterproof Fit For Current Market
  • 9805-300 Electrical Filter Fans For Enclosures IP55 Safe Grade Non Woven Fiber Pad Waterproof Fit For Current Market9805-300 Electrical Filter Fans For Enclosures IP55 Safe Grade Non Woven Fiber Pad Waterproof Fit For Current Market

9805-300 Electrical Filter Fans For Enclosures IP55 Safe Grade Non Woven Fiber Pad Waterproof Fit For Current Market

Place of Origin: China
Brand Name: WONKEDQ,WKDQ
Certification: CE, RoHS, CQC
Model Number: 9805-300
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Send Inquiry

Product Description
Model No.: 9805-300 Air Flowing: 230m³/h
Voltage: 230V Current: 280mA
Weight: 0.403kgs Surface Dimension (mm): 255x255
High Light: electrical enclosure cooling fans , electrical cabinet cooling fans


The fan filter unit is designed to be your economical method to cooling electrical enclosures in environments that are not extremely harsh,The integrated air filters at the system inlet and outlet ensure that the cabinet remains clear of dust and any other contaminating airborne particles.

Frame material is made from heat resistance and anti-flame ABS.

Long durable time.

Reliable and safe function.

Other dimension can be customized.

Made from safe and high quality material.

It can prevent dust particles more than 10 microns.

The protection level of sealed box can reach IP54.

The waterproof hood can make the protection level up to IP55.

The design adapt to current market requirement:Super flat,Fast installation,High power.

It is easy to change the filter pad by using the groove handle on shutter.

The rainproof function of ventilation cascade can prevent mechanical damage and damp entering.

All fan filters’ dimensions comply with the market standards.

When necessary, the filters are also easily replaceable, it is safety to change it during operation.

With the rubber gasket, prevent rain water from entering the enclosure.


TECHNICAL PARAMETERS

Filter unit Part No. 9805-300
Fan with filter unit Part No. 9805-230
Unimpeded air flow 230m³/h
Noise level 54dB
Surface dimension (mm) 255x255
Installation hole size (mm) 224x224
Voltage/Current 230V/280mA
Input Power Rating 41W
Temperature range -10℃~+55℃
Packing detail: 3325-300 (Filter unit) 0.403kgs/pc
Packing detail: 3325-230 (Fitler with Fan) 1.3kgs/pc
Certificate CE, RoHS, CQC
