Ground Push In Connection Terminal Blocks

The Ground Push In Connection Terminal Blocks, made from flame retardant nylon PA66, brass conductors, and stainless steel pressure springs, offer a convenient and efficient solution for configuring your application.

These terminal blocks seamlessly integrate with various types of terminal blocks, including Push-in, spring-cage, fast connection, and screw connection, allowing for flexible configurations tailored to your specific needs. Thanks to their compact design and front connection feature, wiring becomes hassle-free even in tight spaces.

Additionally, these terminal blocks come equipped with a universal foot, facilitating convenient installation on Din Rail NS 35. This feature ensures a secure and stable mounting.

Most importantly, the Ground Push In Connection Terminal Blocks enable seamless electrical interconnection between components, enhancing the reliability and efficiency of your application.

1. Model Number	JPT 2.5/1P-PE
   Color	Green Yellow,other color can be customized
   Length/Height/Wide (mm)	48.5/35.5/5.2
   Connection method	Plug in connection
   Material	Anti inflaming Nylon PA66
   Rated Voltage/Current
   Cross section, solid/soft Cable	0.2-4mm² / 0.2-2.5mm²
   Conductor Size	24-12 AWG
   Mounting Type	NS 35/7.5
   Standard	IEC 60947-7-1
   LOGO	WKDQ, OEM serivce is supporting
   Packing Detail	5.79g/pc, 100PCS/BOX
   Certification	CE/RoHS/CQC/ISO 9001
