Spring Connection Terminal Blocks

Place of Origin: China
Brand Name: WONKEDQ
Certification: CE/RoHS/CQC/ISO 9001
Model Number: JST 4 QUATTRO PE
Packaging Details: Box
Delivery Time: 2-7 days
Payment Terms: T/T, Paypal, Western Union, etc

Model:JST 4 QUATTRO PE

Send Inquiry

Product Description

The spring clamp terminal block adopts screw-free crimping technology. It features a PA66 flame-retardant nylon housing and tin-plated brass guide strips, with anti-corrosion contacts and low-resistance stable connections, making it suitable for vibrating environments. The front-end incoming line + quick-installation spring structure supports second-level installation of DIN rails, making it suitable for demanding scenarios such as industrial automation and power distribution, while balancing efficient operation and maintenance with long-term reliability.

Model No.	JST 4-QUATTRO-PE
Color	Yellow/Green, other color can be customized
Length/Height/Wide (mm)	87/36.5/6.2
Connection method	Spring
Material	Nylon PA66
Rated Voltage/Current	800V/40A
Cross section, solid/soft Cable	0.5-6mm² / 0.5-4 mm²
Conductor Size	20-10 AWG
Mounting Type	NS 35/7.5
Standard	IEC 60947-7-1
LOGO	Customized logo are supported
Packing Detail	17.31g/pc
Certification	CE/RoHS/CQC/ISO 9001
